Specifications
Application
Client PCs
Interface
PCIe Gen 3.0 x 4, NVMe 1.3
Dimension (Pack: WxHxD)
80.15 x 22.15 x 2.38 (mm)
Weight
Max 8.0 g Weight
Performance
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Specifications Detail
General Feature
Application
Client PCs
Rated Capacity
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe Gen 3.0 x 4, NVMe 1.3
Dimension (Pack: WxHxD)
80.15 x 22.15 x 2.38 (mm)
Weight
Max 8.0 g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung in-house controller
Cache Memory
Samsung 1GB Low Power DDR4 SDRAM
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)
Up to 600,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)
Up to 550,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1)
Up to 19,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1)
Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
* Average: 6 W * Maximum: 9 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70 ℃ Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Accessories
Installation Kit
Not Available
Software
Management SW
Magician Software for SSD management
Specifications
Application
Client PCs
Interface
PCIe Gen 3.0 x 4, NVMe 1.3
Dimension (Pack: WxHxD)
80.15 x 22.15 x 2.38 (mm)
Weight
Max 8.0 g Weight
Performance
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Specifications Detail
General Feature
Application
Client PCs
Rated Capacity
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe Gen 3.0 x 4, NVMe 1.3
Dimension (Pack: WxHxD)
80.15 x 22.15 x 2.38 (mm)
Weight
Max 8.0 g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung in-house controller
Cache Memory
Samsung 1GB Low Power DDR4 SDRAM
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)
Up to 600,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)
Up to 550,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1)
Up to 19,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1)
Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
* Average: 6 W * Maximum: 9 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70 ℃ Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Accessories
Installation Kit
Not Available
Software
Management SW
Magician Software for SSD management
Type: | Internal SSD Hard Drive |
Storage Capacity: | 1 TB |
Color: | Black |
Performance: | Up to 3500 MBs |
